Chainway UR5 Wearable RFID reader
RFQ
Or as low as R249,999.75 / month interest-free, using your existing credit card. For orders over R4,000.00.How it works- Android / IOS SDK Supported
- Impinj Gen2X
- ย UHF/RFID Reader
- 900+ tags/sec Read Rate
- 2,000mAh Battery
- IP65
- USB Type C
RFQ
Or as low as R249,999.75 / month interest-free, using your existing credit card. For orders over R4,000.00.How it worksSecure Payment
Dimensions:
108mm ร 78mm ร 18mm
Weight:
200g
Display:
N/A
Operating System:
Android / IOS SDK Supported
CPU:
N/A
RAM & ROM:
N/A
Battery:
2000mAh Removable Battery
Network:
N/A
Bluetooth:
BT 5.0
NFC:
N/A
WiFi:
N/A
GPS:
N/A
VoLTE:
N/A
I/O:
1x USB Type C
IP Rating:
IP65
Drop Certification:
1.5m/ย drops to concrete
Operating Temperature:
Operating Temp:-20 ยฐC to +50 ยฐC
Storage Temp: -40 ยฐC to +70 ยฐC
Humidity:
5%- 95% non condensing
Optional:
N/A
Biometrics:
N/A
UHF / RFID:
UHF RFID
Engine:
CM710-1 module based on Impinj E710
Frequency: 920-925 MHz / 902-928 MHz / 865-868 MHz
Protocol: EPC C1 GEN2 / ISO18000-6C
Antenna: Circular Polarized Antenna (3dBic)
Output Power:
1W (30dBm, support +5~+30dBm adjustable)
2W Optional (33dBm, support +10~+33dBm adjustable, for Latin America, etc.)
Fastest Read Rate: 900+ tags/sec
Max Read Range: 11m (Impinj MR6 tag, size 70 x 15mm)
12m (Impinj M750 tag, size 70 x 15mm)
14m (Alien H3 Anti-Metal tag, size 130 x 42mm)
N/A
N/A
N/A
Warrantyโ:
12 Months Standard Warranty
- Extended Warranty Available
Chainway R5 Wearable UHF RFID reader
Power Adapter
Power Cable
User Manual
