Dimensions:
6.96 in. L x 3.38 in. W x 1.12 in. H/176.8 mm L
x 85.8 mm W x 28.4 mm H; Grip area: 3.179 in.
W x 0.80 in. H/80.75 mm W x 20.3 mm H
Weight:
349g
Display:
6" inch FHD screen
800 nits brightness
1080 x 2160 pixels
Multi Capacitive Touch Panel
Glove Support and Wet modes
Operating System:
Operating System : Android 12
Upgradable up to : Android 16
CPU:
CPU : Qualcomm 6490
CPU Clock : Octa-core, 2.7 GHz
RAM & ROM:
RAM : 8GB
Upgradeable option : 16GB
ROM : 128GB
Upgradable Option : 256GB or 512GB
Battery:
Standard Battery : 4680 mAh
Extended Capacity: 7000 mAh (26.95 Watt hours); BLE battery: 4680 mAh; Qi compatible
Wireless charge battery : 4680 mAh; fast charging, Warm Swap battery mode
Network:
3G Network : B1, 5, 8 ,19; 2G: 850, 900, 1800
4G Network : B1, 3, 5, 7, 8, 19, 34, 38, 39, 40, 41, 42;
5G Network : n1, 3 ,5, 8, 38, 40, 41, 77, 78, 79;
Bluetooth:
5.2
NFC:
ISO 14443 Type A and B; FeliCa and ISO 15693 cards
WiFi:
Wi-Fi 6E Certified; Dual Band Simultaneous; IPv4, IPv6
GPS:
GPS, GLONASS, Galileo, Beidou,
I/O:
1x USB 2.0 (Back I/O — Host Only)
1x USB 3.0 (Bottom Type C) — Super Speed
1xMicroSD card supports up to 2 TB
1x Nano SIM and 1 eSIM
PTT headset (Zebra USB-C) support
IP Rating:
IP65 and IP68 with Battery per applicable IEC sealing specifications
Drop Certification:
Multiple 8 ft./2.4 m drops to concrete over operating temp -20° C to 50° C per MIL-STD 810H
Operating Temperature:
Operating Temperature : -4° F to 122° F/-20° C to 50° C
Storage Temperature : -40° F to 158° F/-40° C to 70° C
Humidity:
5% to 95% non-condensing
Optional:
Barcode Scanning :
SE55 1D/2D Advanced Range Scan Engine with IntelliFocus™ technology; SE4770 1D/2D Scan Engine
Warranty:
1 Year Standard Warranty
Zebra TC78 Mobile Computer
Hot Swappable Battery
User Manual
Warranty
