Zebra MC9400 Rugged Mobile Computer (Wi-fi Only)

RFQ

0.1/5
  • 4.3″ WVGA Screen
  • Android 14
  • 6GB RAM
  • PTT Voice
  • MIL-STD-810H
  • IP65 and IP68
  • PowerPrecision+ Advanced Battery
  • 1D/2D Extended Range Barcode scanner
  • Wi-Fi 6E
  • NFC

RFQ

Request Quote

Secure Payment

Appearance
Dimensions:

240 mm L x 88 mm W x 189 mm H

Weight:

743 g

Display:

4.3''- inch WVGA Display
800 x 480 Resolution
Corning® Gorilla® Glass

Performance
Operating System:

Android 14
Should there be a extended warranty (Life Guard - Zebra OneCare Pack)
Purchased with the device

CPU:

CPU : Qualcomm
CPU Clock : 4490 octa-core; 2.4 GHz

RAM & ROM:

RAM : 6GB
ROM : 128GB

Battery:

Rechargeable Li-Ion: 3.6V, 7000mAh (25.20 Wh); Optional BLE Battery Li-Ion 3.6V, 7000mAh (25.20 Wh); Optional Freezer Capacity battery — 5000mAh (18.80 Wh); Optional 7000mAh (25.20 Wh) Non-Incendive battery; Hot swap battery backup with temporary session persistence

Connectivity
Network:

N/A

Bluetooth:

Class 2, Bluetooth v5.3 and Secondary BLE for beaconing within BLE battery

NFC:

ISO 14443 Type A and B; FeliCa and ISO 15693 cards

WiFi:

IEEE 802.11 a/b/g/n/ac/ax/d/h/i/r/k/v/w/mc

GPS:

N/A

VoLTE:

N/A

I/O
I/O:

MicroSD supports up to 2 TB
Speaker and microphone
USB 2.0 (bottom pogo connector) — high speed (host and client)

Certifications
IP Rating:

IP65 and IP68 with battery per applicable IEC sealing specifications

Drop Certification:

Exceeds per MIL-STD-810H: 12 ft./3.65 m to concrete; Enterprise drop standard 8 ft. (2.4 m) to concrete across temperature (-20°C to 50°C) exceeding MIL-STD-810H Freezer version: 7 ft. (2.1 m) to concrete (-30°C to 50°C) exceeding MIL-STD810H
Tumble Specification : 6,000 3.3 ft. (1m) tumbles; meets or exceeds IEC tumble specification

Operating Temperature:

Standard: -4°F to 122°F/-20°C to +50°C
Freezer:
-22°F to 122°F/-30°C to +50°C

Storage Temperature : -40°F to 158°F/-40°C to 70°C

Humidity:

Standard: 5%-95% non-condensing
Freezer: 5%-95% condensing (condensation resistant model with heaters for scanner exit window and touch panel glass)

Expansion
Optional:

N/A

Biometrics:

N/A

UHF / RFID:

N/A

Physical Characteristics
Performance
Product Specifications

Vibration :4 g’s PK Sine (5 Hz to 2 kHz); 0.04 g 2/Hz Random (20 Hz to 2 kHz); 60 minute duration per axis, 3 axis
Electrostatic Discharge (ESD) :
+/- 15 kV air discharge; +/- 8 kV direct discharge; +/- 8 kV indirect discharge

Scanning :SE58 1D/2D Extended Range Scan Engine with IntelliFocus™ technology with green laser aimer SE4770 1D/2D Scan Engine with red laser aimer

Camera :Front: 8 MP; Rear: 16 MP autofocus; flash LED generates balanced white light; supports Torch mode + HDR (standard)

Interactive Sensor Technology (IST)
Light Sensor :
Automatically adjusts display backlight brightness
Magnetometer :
eCompass automatically detects direction and orientation
Motion Sensor :
3-axis accelerometer with MEMS Gyro

Features
Warranty​:

1 Year Standard Warranty

Zebra MC9400 Mobile Computer
USB Cable
User Manual
