ONERugged M10A Rugged Tablet, Intel® Core™ i5-1235U Processor
RFQ
- 10.1″ FHD+ Screen
- Windows 11 Pro
- 16GB RAM
- 128GB ROM
- 700 Nits
- 5,000mAh Removable Li-polymer Battery
- 860mAh Built-in Battery
- Intel® Core™ i5-1235U Processor
- Supports Glove Touch
- MIL-STD-810H
- Working temperature: -20 °C to 60 °C
RFQ
Secure Payment
Dimensions:
292.1 x192.1 x 28.9mm
Weight:
1290g
Display:
10.1'' FHD IPS Screen
1200 x 1920 Resolution
700 Nits Brightness
10 Points Capacitive TP, G+G, Hardness over 7H
Scratch resistant
Support glove touch
Operating System:
Windows 11 Pro
CPU:
CPU: Intel® Core™ i5-1235U Processor
CPU: TDP15W, 2P-Cores, 10E-Cores, 12threads, 0.9GHz~4.4GHz
GPU: Intel® Iris® Xe Graphics eligible
RAM & ROM:
RAM: 16GB (DDR4L)
ROM: 128GB (SSD)
Supports up to: 128GB
Battery:
Build in Lithium-ion polymer battery, 7.4V/860mAh
Removable Li-polymer Battery, 7.4V/5000mAh
Built-in RTC battery
Adapter (input AC 100V~240V 50Hz/60Hz, output DC 19V/3.42A)
Camera:
Front Camera: 2MP Rear Main Camera: 8MP with AF and Flash
Rear Camera:
8.0MP
Front camera:
5.0MP
Network:
GSM: 900/ 1800
WCDMA: B1/ 5/ 8
LTE-FDD: B1/ 3/ 5/ 7/ 8/ 20
LTE-TDD: B40
Bluetooth:
BT5.1 (BLE) class1
Transmitted distance: 10m
NFC:
13.56MHz
supports: 14443A/14443B/15693/18092/mifare protocol under ISO/IEC
Optional
NXP300
WiFi:
(Wi-Fi 6)
802.11 (a,b,d,e,g,h,i,k,n,r,u,v,w,ac,ax) Dual frequency 2.4G+5.8G WIFI
GPS:
GPS + GLONASS + Beidou + U-blox M7N
Optional
U-blox M8Q
I/O:
1 x USB 3.1
1 x USB Type-C (Full function/HDMI/Charging)
1 x ∮3.5mm Standard Earphone jack
1 x HDMI 2.1a Mini
1 x Sim/TF Card
1 x DC 19V3.42A
1 x 12Pin Pogo Pin (USB/Docking charging)
IP Rating:
IP65
Certification
CE, CCC, FCC
Battery Certification
Battery: UN3803, MSDS, IEC62133, aviation report, marine report
Drop Certification:
MIL-STD-810H
Operating Temperature:
Working temperature: -20 °C to 60 °C
Storage temperature: -30 °C to 70 °C
Humidity:
95% Non-Condensing
Optional:
Ethernet Interface: RJ45 (Standard 10/100/1-00M) x 1
Optional Replacement: RS323 (9-line full function) or 2D Barcode Scanner
Biometrics:
Fingerprint
Warranty:
- 36-Months warranty on all ONERugged branded products
- 1-year warranty on all accessories including battery
- ONERugged units already sold to clients will carry the 36 Months warranty
- No physical damage is covered under warranty, including water damage
- Any non-branded ONERugged products will carry the standard 1 Year warranty
One Rugged M10A Rugged Tablet
Adapter
Carry Handle
Hand-strap
(Optional Accessories)
- Docking station for M10A, charge device with extra battery
- 7.4V/5000mAh Battery for M10A
- Vehicle Charger
- Vehicle Mount
- Carry Handle
- Shoulder Strap
1 x ONERugged M10A Rugged Tablet
1 x Hand-strap
1 x Carry Handle
1 x Adapter
