Rugged SA Chainway P80 Scanning Tablet

Chainway - P80 Android 1D/2D - RFID - Biometric Rugged Scanning Tablet



Please contact us @ sales@ruggedsa.co.za or 010 020 5540 for more information on all scanners

LOCAL WARRANTY & SUPPORT

WHY BUY LOCAL VS IMPORT?


Rugged SA Chainway South Africa

Chainway - P80 Android 1D/2D Rugged RFID Scanning Tablet

8'' Screen & 8000mAh Battery, Abundant Functions Available

This is an Android 7.1.2 rugged tablet with abundant functions. With its powerful Qualcomm CPU, 3rd generation corning gorilla 8 inches corning high-definition screen, 8000 mAh battery and comprehensive data capture options like UHF RFID, barcode scanning, HF RFID/NFC, Iris and fingerprint recognition, etc. You can find this easy-to-deploy device a valuable helper to increase productivity in retail, logistics, warehousing, identity verification, meter reading, etc.

Key Features...

Rugged SA Chainway South Africa

Rugged SA Chainway P80 Rugged Scanning Tablet

Rugged SA Chainway P80 Rugged Optical Fingerprint Scanning Tablet

Rugged SA Chainway P80 Rugged Optical Fingerprint Scanning Tablet

Rugged SA Chainway P80 Rugged Optical Fingerprint Scanning Tablet

Rugged SA Chainway P80 Rugged Optical Fingerprint Scanning Tablet

Rugged SA Chainway P80 Rugged Optical Fingerprint Scanning Tablet

Rugged SA Chainway P80 Rugged Optical Fingerprint Scanning Tablet

Rugged SA Chainway P80 Rugged Optical Fingerprint Scanning Tablet

Rugged SA Chainway P80 Rugged Optical Fingerprint Scanning Tablet

Rugged SA Chainway P80 Rugged Optical Fingerprint Scanning Tablet



Physical Characteristics

Dimensions 250.8mm x 152mm x 15mm/ 9.87 x 5.98 x 0.59in(for standard version)
Weight 700g/24.7oz(for the standard version)
Display 8'' IPS LTPS 1920x1200
Touch Panel Corning Gorilla Glass 3, multi-touch panel, gloves, and wet hands supported
Power Main battery: Li-ion, rechargeable, 8000mAh Standby: over 500 hours
Continuous use: over 10 hours (depending on user environment)
Charging time: 5-7 hours (with standard AC adaptor and USB cable)
Expansion Slot 1 slot for SIM card, 1 slot for TF card, Optional PSAM card slot
Interfaces USB 3.0 Type-C, OTG
Audio Speaker, microphone
Keypad 1 front key, 1 volume key, 1 power key
Sensors Gravity sensor

Performance

CPU Qualcomm Snapdragon 625 / MSM8953 2.0GHz Octa-core
RAM+ROM 2GB+16GB//3GB+32GB
Expansion Supports up to 128GB Micro SD card

Communication

WLAN IEEE802.11 a/b/g/n/ac, 2.4G/5G dual-band, internal antenna
WWAN 2G: 850/900/1800/1900MHz, GPRS, EDGE
3G: CDMA EVDO: BC0
TD-SCDMA: B34/B39
WCDMA: B1/B2/B5/B8
4G: TDD-LTE: B38/B39/B40/B41
FDD-LTE: B1/B2/B3/B4/B5/B7/B8/B20/B26/B28

PSAM

Protocol ISO7816
Slots 2 PSAM card slot
Note *This function is optional

Barcode Scanning

Scan engine Zebra SE4710 (standard), Zebra SE4850 (optional)
1D Symbologies UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
2D Symbologies PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch, Postal (KIX), etc.

NFC

Frequency 13.56MHz
Protocol ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc.
Chips M1 card (S50, S70), CPU card, NFC tags, etc.
Range 2-4cm
Note * This function is optional

UHF RFID

Engine CM2000-1 module based on Impinj Indy R2000
Frequency 865MHz-868MHz / 920-925MHz / 902-928MHz
Protocol EPC C1 GEN2 / ISO18000-6C
Antenna Circular polarization (default UHF, 3dBi ; UHF with pistol grip, 4dBi)
Power 1W (30dBm, +5dBm to +30dBm adjustable)
R/W ranges > 10m (open outdoors); > 25m (indoors)
Reading rates (circular polarization) >200 tags/s
Note * Ranges and rates depend on tags and environment

HF RFID

Frequency 13.56MHz
Note * This function is optional
Note2 * HF RFID is alternative to NFC

User Environment

Operating Temp. -4oF to 122oF / -20oC to 50oC
Storage Temp. -40oF to 158oF / -40oC to 70oC
Humidity 5%RH - 95%RH non condensing
Drop Specification Multiple 1.5m/4.9ft drops to concrete across the operating temperature range
Tumble Specification 500 x 0.5m/1.64ft falls at room temperature
Sealing IP 65. Complete protection against contact (dust tight). Water projected by a nozzle (6.3 mm) against enclosure from any direction shall have no harmful effects.
ESD ±15KV air discharge, ±8KV conductive discharge

Developing Environment

Operating System Android 7.1.2
SDK Chainway Software Development Kit
Language Java
Tool Eclipse / Android Studio

Fingerprint

Sensor TCS1/TCS2 Capacitive; Optical Morpho CBM-E3
Sensing Area (mm) 12.8×18; 10.4x14.4; 14x22
Resolution (dpi) 508 dpi, 8-bit greylevel; 500 dpi, 256 greylevel
Certifications FIPS 201, STQC; FIPS PIV IQS / ISO 19794-4, MINEX & FIPS 201 complaint, STQC
Format Extraction ISO 19794, WSQ, ANSI 378, JPEG2000; ISO 19794-2/4, WSQ, ANSI 378, etc.
Security AES, DES key encryption of the host communication channel; FIPS 140-2 level 2, multiple security methods available, including image and templates encryption, template signature, secure tunneling, etc.
Fake Finger Detection Support by SDK; Latex, Gelatin, Plasticine, Kapton, Transparent Film, Silicone, Rubber, Play-doh, Graphite Or Paper
Note * This function is optional

InfraRed

Wavelength 940nm
Frequency 38kHz
Range >4m
Protocol DLT_645-2007, DLT_645-1997
Note *This function is optional

Camera

Front Camera 8MP
Rear Camera 13MP Autofocus with flash

Iris Recognition

Rate <150ms
Range 20-40cm
FAR 1/10000000
Note Protocol:ISO/IEC 19794-6,GB/T 20979-2007
Note2 * This function is optional.
* Front Iris
